ClaryFlow Big Buddy Pleated Cartridge Filter is popularly used for typical water filtration applications. It offers more surface area for greater throughput at reduced cost. The cartridges come with EPDM (Ethylene Propylene Diene Monomer) double O-ring seals for superior performance and are easy to install, service, and replace.

Features and Benefits

  • High dirt holding due to extended surface area
  • They remove sediment and hard solids for high efficiency filtration requirements
  • Available in a wide range of micron ratings, including one micron absolute
  • Apt for surface water filtration to reduce Giardia Cycts and Cryptosporidium
Applications

Water filtration for

  • Residential Properties
  • Commercial Facilities
  • Industrial Applications
Specifications
  • Filter Media
    PP(Pleated)
    Endcaps, Core*
    PP & FG
    Center Tubes
    PP
  • Maximum Flow Rate*
    150 gpm (36 m3/hr)
    Maximum temperature
    125℉ (52℃)
    Maximum working pressure
    125 psi (8.75 bar)
    Maximum change pressure
    30 psi (2 bar)
    Chemical Resistance
    Excellent
    Length (media)
    30”
    O-ring (dual)
    Silicon, Buna-N, FKM, EPDM



Check out other ClaryFlow Pleated Big Buddy Cartridge Filter Variants:





All ClaryFlow Big Buddy cartridge filters are:

•  All polypropylene construction using best quality polypropylene
•  Apt for high flow rates from 379 to 568 LPM (100 to 150 GPM)
•  Filters at operating temperature as high as 79.44 °C (175 F)
•  Excellent chemical resistance
•  100% free from resin binders, lubricants, antistatic and release agents
•  Engineered for a long service life and excellent filtration capacity
